Produktfoto des Vakuumhebegeräts Aero-Select der Firma Aero-Lift

Aero-Select

SHEET METAL / PLASTICS

Forklift device, adaptable to almost all forklift forks. Convenient operation from the driver's cab thanks to the remote control panel.

  • Metal sheets
  • Glass
  • Plastics
  • Panels
  • Horizontal pick
  • Up to 2.000 kg < 2000 kg

Strengths of the Aero-Select

Self-sufficient power pack: Can be adapted to almost any forklift from well-known manufacturers thanks to the universally adjustable forklift pockets

Damage-free and gentle transportation thanks to the outstanding-quality full elastomer seals with an extremely long service life

Maximum versatility as it can be used on both crane hooks and forklift pockets

Maximum process reliability because of the robust welded steel construction of the frame and crossbars

Real-time display of the vacuum level thanks to the large all-round lights, which provide information on the operational readiness of the system.

Guaranteed work and operator safety thanks to the generously dimensioned vacuum reservoir with an intelligent warning device

Network-independent/battery-powered version with a guaranteed long battery life and short charging cycles. The battery status can be seen at all times on the battery indicator.

Short set-up times for different transport good dimensions due to suction plates that can be individually locked in place using manual slide valves (already included in the basic package)

Battery-saving and performance-maximising operation due to the intelligent pump control, which regulates the activity level of the vacuum pump (already included in the basic package).

Quick and easy maintenance: The intelligent suction plate concept enables worn suction seals to be replaced in seconds with virtually no tools.

Compact design to maximise the driver's field of vision

Protection against moisture and dirt thanks to the integrated water separator

Convenient operation from the driver's cab as the suction and release process can be controlled by the forklift driver via a remote control panel.

Dimensional drawing

Technische Zeichnung des Vakuumhebegeräts Aero-Select der Firma Aero-Lift

Product variants

The AERO-SELECT vacuum lifter is available in different versions with:

  • load capacities from 150 to 2,000 kg
  • 4 to 8 suction plates
  • 2 to 4 crossbars
  • different suction plate diameters, cross beam lengths, etc.

We will be happy to advise you on the selection of the right device for your application.

Application images

    Anwendungsaufnahme des Vakuumhebegeräts Aero-Select von Aero-Lift, das eine Blechplatte hebt
    Nahaufnahme eines Saugers des Vakuumhebegeräts Aero-Select von Aero-Lift
    Anwendungsbild des Vakuumhebegeräts Aero-Select, wie es an einem Stapler adaptiert ist

Product video

Optional configuration / accessories

3.0-metre main cross beam

Extension of the main lifting beam to 3.0 m to compensate for the overhang at both ends when lifting maxi format sheets

Article code suffix: E.g. AE-SELECT 600/8R/3000
Show all Show less

ORDER Aero-Select

for more safety, ergonomics & efficiency!

Aero-Customised

Exactly according to your requirements

Can't find the right lifting device? We are also happy to offer you customised solutions for your specific challenge.
